nanoCH32V203 Dev Board

These are all purchase variations of this page.  The chip is the new 10 cent RISC-V.

 https://www.tindie.com/products/johnnywu/nanoch32v203-development-board/
https://www.tindie.com/products/johnnywu/wch-linke-debugger/

nanoCH32V203 Development Board WCH RISC-V Dual TYPE-C USB Interface LCD Interface SD Card Slot Open Source

nanoCH32V203 is a development board made by MuseLab based on CH32V203C8T6 of QinHeng. It features dual TYPE-C USB interfaces, LCD interface and SD card slot on board, and can be programmed through the USB port which is convenient for prototype verification and development.

  • Dual USB interface, USB1 supports Device, USB2 supports Host/Device
  • Can be downloaded directly via USB without additional downloader
  • Onboard 8MHz and 32.768K crystal oscillator
  • FPC-12P cable connector, which can support common LCD (such as ili9341, st7789, etc.)
  • SD card slot, which supports SD card reading and writing (SPI protoc

    ol)
  • Kit 3: nanoCH32V203 Development Board x 1 + 20 Pin Header x 2 + 1.54 Inch Screen ( 240*240 ) x 1




nanoCH32V003 Development Board WCH RISC-V TYPE-C USB Interface Reset Button LED 1-Wire Serial Debug Interface Open Source
Note: CH32V003 can only be programmed by WCHLink-E through SDI interface (1-wire serial debug interface), so if it is the first time to buy the board, please buy it together with WCHLink-E.

Introduction
nanoCH32V003 is a development board made by MuseLab based on CH32V003F4U6 of QinHeng. It features 24MHz crystal oscillator，reset button and LED on board. It supports 1-wire serial debug interface (SDI) and all GPIOs are led out, which is convenient for developers to develop and prototype.

Features

  • Onboard 24MHz crystal oscillator
  • Onboard reset button
  • LED indicator
  • Powered by TYPE-C USB
  • Lead out all GPIOs
  • 1-wire serial debug interface (SDI)
Documentation
  • https://github.com/wuxx/nanoCH32V003
  • The MoanRiver IDE is a bit odd but after going over several you tube videos I got it to work.
